000-009
SRO-KIT intake system air outing
| Pos. | Pièce n°. | Description | Remarques | Qté | Modèle |
|---|
| 1 | 9F2129687 | BRACKET AIR FILTER LEFT
| | 1 | MOTORSPORT |
| 2 | 9F2129687A | BRACKET AIR FILTER RIGHT
| | 1 | MOTORSPORT |
| 3 | 9F2129648 | BRACKET AIR FILTER MID
| | 1 | MOTORSPORT |
| 4 | N 90944604 | N90944604 - OVAL HEAD SCREW M5X12
| | 18 | |
| 5 | N 91016702 | N91016702 - BLIND RIVET NUT
| | 18 | |
| 6 | N 91244501 | N91244501 - HEX SCREW M6X35
| | 2 | |
| 7 | N 90236203 | N90236203 - TAB WASHER
| | 1 | |
| 8 | 9F2121326 | WIRE CLAMP
| | 6 | MOTORSPORT |
| 9 | 9F2129627A | INTAKE HOSE
| | 1 | MOTORSPORT |
| 10 | WHT009778 | OVAL HEAD SCREW M6X25
| | 4 | MOTORSPORT |
| 11 | 9F2129657 | TUBE SUCTION-AIR
| | 1 | MOTORSPORT |
| 12 | 9F2129559 | BRACKET
| | 1 | MOTORSPORT |
| 13 | 99951262900 | 99951262900 - HOSE CLAMP 90-110/ 9D 3017 W3
| | 2 | |
| 14 | 9911106219A | RUBBER SLEEVE THROTTLE
| | 1 | MOTORSPORT |
| 15 | 9F2115467 | TUBE
| | 1 | MOTORSPORT |
| 16 | 9F2115459 | CONNECTION TUBE
| | 1 | MOTORSPORT |
| 17 | 9F2115295 | Z OIL FILLING LINE
| | 1 | MOTORSPORT |
| 18 | 9F2815373A | HOSE AIR SUCTION
| | 2 | MOTORSPORT |
| 19 | 9F2853989 | Z COVER REAR LEFT
| | 1 | MOTORSPORT |
| 20 | 9F2853990 | Z COVER REAR RIGHT
| | 1 | MOTORSPORT |
| 21 | 9F2071718 | TEMPLATE BULKHEAD
| | 1 | MOTORSPORT |
| 22 | 99951308040 | CABLE TIE 3.0-76.0 PA66 SW
| | 6 | MOTORSPORT |
